14.5ton Cold Milling Machine XM101



Quick Details

Feature: Cold Milling Machine

Condition: New

Application: Construction

Brand Name: XCMG

Model Number: XM101

Certification: ISO,CE

Max mix depth: 120mm

Max. Grade Ability: 20%

Dimension:  4583*2294*3130mm

Total Weight: 14.5t

Engine: SC8D170G2B1

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Color: Yellow

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

7~15 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

XM101

Overall length

mm

4583

Overall width

mm

2294

Overall height

mm

3130

Belt conveyor length

mm

6428

Belt conveyor width

mm

700

Belt conveyor height

mm

610

Aggregate belt conveyor width

mm

400

Weight





Total weight

kg

14500

Power





Engine model



SC8D170G2B1

Engine rated power

kW

125

Engine rated speed

r/min

2200

Travel





Operating speed

km/h

0~13

Travel speed

km/h

0~13

Main performance





Max. milling width

mm

120

Max. milling depth

mm

120

Drum diameter with tools

mm

660

Number of tools


84

Fuel tank

L

210

Hydraulic oil tank

L

160

Water tank

L

360

Gradeability

%

20

Min. ground clearance

mm

120
