100ton Crawler Crane QUY100



Quick Details

Feature: Crawler Crane

Condition: New

Application: Construction

Brand Name: ZOOMLION

Model Number: QUY100

Certification: ISO,CE

Rated Loading Capacity: 100t

Rated Lifting Moment: 5359kN.M

Dimension: 9500*6000*3500mm

Max. Lifting Load: 100t

Max. Lifting Height: 79m

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Span: 11

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

10 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

QUY100

Overall length

mm

9500

Overall width

mm

6000

Overall height

mm

3500

Weight





Total mass (with basic boom)

t

110

Balance weight

t

Power





Engine model



Engine rated power

kW/(r/min)

209/2100

Engine rated torque

N.m/(r/min)

1425/1400

Travel





Max. travel speed

km/h

0~1.3

Max. grade ability

%

30

Mean ground pressure

MPa

0.1

Main performance





Max. rated total lifting capacity

t

100

Max. lifting torque

kN.m

5359

Base boom

m

19

Fully extended boom

m

73

Fully extended boom+ jib

m

104

Boom elevating angle

°

Working speed





Max. swing speed

r/min

0~2.2

Max. single rope hoist speed

m/min

110

Max. single rope boom luffer speed

m/min

45
