6.3 Tons Truck Mounted Cranes SQ6.3SK3Q



Quick Details

Feature: Truck Mounted Crane

Condition: New

Application: Construction

Brand Name: XCMG

Model Number: SQ6.3SK3Q

Certification: ISO,CE

Rated Loading Capacity: 6.3t

Rated Lifting Moment: 153.86kN.M

Span: 11m

Max. Lifting Load: 6.3t

Max. Lifting Height: 13m

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Color: Yellow

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

20 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Main performance

Unit

SQ6.3SK3Q

Crane Weight

kg

2117/2270

Max. rated total lifting capacity

kg

6300

Max. lifting torque

kN.m

153.86

Recommend Power

kw

20

Max Oil Flow of Hydraulic System

L/min

40

Max Pressure of Hydraulic System

MPa

20

Oil Tank Capacity

L

90

Rotation Angle


360°All Rotation

Installation Space

mm

900

Choice of Chassis


CA1163P7K2L3E, EQ1126KJ1, etc.

Lifting capability diagram





Working radius

m

2.5/3.96/6.3/8.6/11

Lifting capacity

kg

6300/2800/1600/1200/600
