Quick Details Feature: Truck Crane Condition: New Application: Construction Brand Name: ZOOMLION Model Number: QY50V Certification: ISO,CE Rated Loading Capacity: 50t Rated Lifting Moment: 1764kN.M Dimension: 13300×2750×3650mm Max. Lifting Load: 50t Max. Lifting Height: 58.3m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: white After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit QY50V Overall length mm 13300 Overall width mm 2750 Overall height mm 3650 Weight Total weight in travel kg 41000 Front axle load kg 17200 Rear axle load kg 23800 Power Engine model WP10.336 Engine rated power kW/(r/min) 247/2200 Engine rated torque N.m/(r/min) 1250/1200~1600 Travel Max. travel speed km/h 76 Min. turning diameter m 12 Min. ground clearance mm 280 Approach angle ° Departure angle ° Max. grade ability % 40 Fuel consumption for 100km L 48 Main performance Max. rated total lifting capacity kg 50000 Min. rated working radius m Turning radius at turntable tail m Max. lifting torque kN.m 1746 Base boom m 11.6 Fully extended boom m 42.1 Fully extended boom+ jib m 58.3 Longitudinal outrigger span m Lateral outrigger span m Working speed Boom luffing time s 50 Boomfull extension time s 95 Max. swing speed r/min 0~2 Max. speed of main winch (single rope) (no load) m/min 130 Max. speed of aux. winch (single rope) (no load) m/min 72
Feature: Truck Crane
Condition: New
Application: Construction
Brand Name: ZOOMLION
Model Number: QY50V
Certification: ISO,CE
Rated Loading Capacity: 50t
Rated Lifting Moment: 1764kN.M
Dimension: 13300×2750×3650mm
Max. Lifting Load: 50t
Max. Lifting Height: 58.3m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: white
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit QY50V Overall length mm 13300 Overall width mm 2750 Overall height mm 3650 Weight Total weight in travel kg 41000 Front axle load kg 17200 Rear axle load kg 23800 Power Engine model WP10.336 Engine rated power kW/(r/min) 247/2200 Engine rated torque N.m/(r/min) 1250/1200~1600 Travel Max. travel speed km/h 76 Min. turning diameter m 12 Min. ground clearance mm 280 Approach angle ° Departure angle ° Max. grade ability % 40 Fuel consumption for 100km L 48 Main performance Max. rated total lifting capacity kg 50000 Min. rated working radius m Turning radius at turntable tail m Max. lifting torque kN.m 1746 Base boom m 11.6 Fully extended boom m 42.1 Fully extended boom+ jib m 58.3 Longitudinal outrigger span m Lateral outrigger span m Working speed Boom luffing time s 50 Boomfull extension time s 95 Max. swing speed r/min 0~2 Max. speed of main winch (single rope) (no load) m/min 130 Max. speed of aux. winch (single rope) (no load) m/min 72
Dimension
Unit
QY50V
Overall length
mm
13300
Overall width
2750
Overall height
3650
Weight
Total weight in travel
kg
41000
Front axle load
17200
Rear axle load
23800
Power
Engine model
WP10.336
Engine rated power
kW/(r/min)
247/2200
Engine rated torque
N.m/(r/min)
1250/1200~1600
Travel
Max. travel speed
km/h
76
Min. turning diameter
m
12
Min. ground clearance
280
Approach angle
°
Departure angle
Max. grade ability
%
40
Fuel consumption for 100km
L
48
Main performance
Max. rated total lifting capacity
50000
Min. rated working radius
Turning radius at turntable tail
Max. lifting torque
kN.m
1746
Base boom
11.6
Fully extended boom
42.1
Fully extended boom+ jib
58.3
Longitudinal outrigger span
Lateral outrigger span
Working speed
Boom luffing time
s
50
Boomfull extension time
95
Max. swing speed
r/min
0~2
Max. speed of main winch (single rope) (no load)
m/min
130
Max. speed of aux. winch (single rope) (no load)
72
