Quick Details Feature: Crawler Crane Condition: New Application: Construction Brand Name: ZOOMLION Model Number: QUY50 Certification: ISO,CE Rated Loading Capacity: 55t Rated Lifting Moment: 750kN.M Dimension: 6800*3300*3020mm Max. Lifting Load: 55t Max. Lifting Height: 52m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: White After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit QUY50 Overall length mm 6800 Overall width mm 3300 Overall height mm 3020 Weight Total mass (with basic boom) t 49 Balance weight t 16.5 Power Engine model TBD226B-61G3 Engine rated power kW/(r/min) 140/1900 Engine rated torque N.m/(r/min) 830/1300 Travel Max. travel speed km/h 0～1.7 Max. grade ability % 40 Mean ground pressure MPa 0.066 Main performance Max. rated total lifting capacity t 55 Max. lifting torque kN.m 750 Base boom m 13 Fully extended boom m 52 Fully extended boom+ jib m 67 Boom elevating angle ° 30~81 Working speed Max. swing speed r/min 0~2.6 Max. single rope hoist speed m/min 125 Max. single rope boom luffer speed m/min 60
Feature: Crawler Crane
Condition: New
Application: Construction
Brand Name: ZOOMLION
Model Number: QUY50
Certification: ISO,CE
Rated Loading Capacity: 55t
Rated Lifting Moment: 750kN.M
Dimension: 6800*3300*3020mm
Max. Lifting Load: 55t
Max. Lifting Height: 52m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: White
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit QUY50 Overall length mm 6800 Overall width mm 3300 Overall height mm 3020 Weight Total mass (with basic boom) t 49 Balance weight t 16.5 Power Engine model TBD226B-61G3 Engine rated power kW/(r/min) 140/1900 Engine rated torque N.m/(r/min) 830/1300 Travel Max. travel speed km/h 0～1.7 Max. grade ability % 40 Mean ground pressure MPa 0.066 Main performance Max. rated total lifting capacity t 55 Max. lifting torque kN.m 750 Base boom m 13 Fully extended boom m 52 Fully extended boom+ jib m 67 Boom elevating angle ° 30~81 Working speed Max. swing speed r/min 0~2.6 Max. single rope hoist speed m/min 125 Max. single rope boom luffer speed m/min 60
Dimension
Unit
QUY50
Overall length
mm
6800
Overall width
3300
Overall height
3020
Weight
Total mass (with basic boom)
t
49
Balance weight
16.5
Power
Engine model
TBD226B-61G3
Engine rated power
kW/(r/min)
140/1900
Engine rated torque
N.m/(r/min)
830/1300
Travel
Max. travel speed
km/h
0～1.7
Max. grade ability
%
40
Mean ground pressure
MPa
0.066
Main performance
Max. rated total lifting capacity
55
Max. lifting torque
kN.m
750
Base boom
m
13
Fully extended boom
52
Fully extended boom+ jib
67
Boom elevating angle
°
30~81
Working speed
Max. swing speed
r/min
0~2.6
Max. single rope hoist speed
m/min
125
Max. single rope boom luffer speed
60
