Quick Details Feature: All Terrain Crane Condition: New Application: Construction Brand Name: ZOOMLION Model Number: QAY220 Certification: ISO,CE Rated Loading Capacity: 220t Rated Lifting Moment: 7650kN.M Dimension: 16722×3000×3980mm Max. Lifting Load: 220t Max. Lifting Height: 62.6m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Span: 8.8/8.8m After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit QAY220 Overall length mm 16722 Overall width mm 3000 Overall height mm 3980 Weight Total weight in travel kg 72000 Front axle load kg 12000 Rear axle load kg 12000 Power Engine model OM502LA Engine rated power kW/(r/min) 420/1800 Engine rated torque N.m/(r/min) 2700/1080 Travel Max. travel speed km/h 72 Min. turning diameter m 24 Min. ground clearance mm 305 Approach angle ° Departure angle ° Max. grade ability % 50 Fuel consumption for 100km L 85 Main performance Max. rated total lifting capacity t 220 Min. rated working radius m Turning radius at turntable tail m Max. lifting torque kN.m 7650 Base boom m 13.8 Fully extended boom m 61 Fully extended boom+ jib m 95 Longitudinal outrigger span m 8.8 Lateral outrigger span m 8.8 Working speed Boom luffing time s ≥90 Boomfull extension time s 600 Max. swing speed r/min ≤1.5 Max. speed of main winch (single rope) (no load) m/min 124 Max. speed of aux. winch (single rope) (no load) m/min 70
Feature: All Terrain Crane
Condition: New
Application: Construction
Brand Name: ZOOMLION
Model Number: QAY220
Certification: ISO,CE
Rated Loading Capacity: 220t
Rated Lifting Moment: 7650kN.M
Dimension: 16722×3000×3980mm
Max. Lifting Load: 220t
Max. Lifting Height: 62.6m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Span: 8.8/8.8m
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit QAY220 Overall length mm 16722 Overall width mm 3000 Overall height mm 3980 Weight Total weight in travel kg 72000 Front axle load kg 12000 Rear axle load kg 12000 Power Engine model OM502LA Engine rated power kW/(r/min) 420/1800 Engine rated torque N.m/(r/min) 2700/1080 Travel Max. travel speed km/h 72 Min. turning diameter m 24 Min. ground clearance mm 305 Approach angle ° Departure angle ° Max. grade ability % 50 Fuel consumption for 100km L 85 Main performance Max. rated total lifting capacity t 220 Min. rated working radius m Turning radius at turntable tail m Max. lifting torque kN.m 7650 Base boom m 13.8 Fully extended boom m 61 Fully extended boom+ jib m 95 Longitudinal outrigger span m 8.8 Lateral outrigger span m 8.8 Working speed Boom luffing time s ≥90 Boomfull extension time s 600 Max. swing speed r/min ≤1.5 Max. speed of main winch (single rope) (no load) m/min 124 Max. speed of aux. winch (single rope) (no load) m/min 70
Dimension
Unit
QAY220
Overall length
mm
16722
Overall width
3000
Overall height
3980
Weight
Total weight in travel
kg
72000
Front axle load
12000
Rear axle load
Power
Engine model
OM502LA
Engine rated power
kW/(r/min)
420/1800
Engine rated torque
N.m/(r/min)
2700/1080
Travel
Max. travel speed
km/h
72
Min. turning diameter
m
24
Min. ground clearance
305
Approach angle
°
Departure angle
Max. grade ability
%
50
Fuel consumption for 100km
L
85
Main performance
Max. rated total lifting capacity
t
220
Min. rated working radius
Turning radius at turntable tail
Max. lifting torque
kN.m
7650
Base boom
13.8
Fully extended boom
61
Fully extended boom+ jib
95
Longitudinal outrigger span
8.8
Lateral outrigger span
Working speed
Boom luffing time
s
≥90
Boomfull extension time
600
Max. swing speed
r/min
≤1.5
Max. speed of main winch (single rope) (no load)
m/min
124
Max. speed of aux. winch (single rope) (no load)
70
