Quick Details
|
Feature: Wheel Loader
|
Condition: New
|
Application: Construction
|
|
Brand Name: SDLG
|
Model Number: LG952L
|
Certification: ISO,CE
|
|
Rated Loading Capacity: 5.0t
|
Bucket Capacity: 2.7m3
|
Dimension: 7600×3024×3349mm
|
|
Max. Lifting Load: 5.0t
|
Engine: WD10G220E23
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Color: Yellow
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
7~15 days
|
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
|
Dimension
|
Unit
|
LG952L
|
|
Overall length
|
mm
|
7600
|
|
Overall width
|
mm
|
3024
|
|
Overall height
|
mm>
|
3349
|
|
Weight
|
|
|
|
Total weight
|
kg
|
16400~16450
|
|
Power
|
|
|
|
Engine model
|
|
WD10G220E23
|
|
Engine rated power
|
kW
|
162
|
|
Engine rated speed
|
r/min
|
2000
|
|
Travel
|
|
|
|
Travel speed 1st (forward/backward)
|
km/h
|
0~13/0~17
|
|
Travel?speed 2st (forward/backward)
|
km/h
|
0~38
|
|
Main performance
|
|
|
|
Rated load
|
t
|
5.0
|
|
Bucket capacity
|
m3
|
2.7
|
|
Dumping clearance
|
m
|
3.11~3.45
|
|
Dumping reach
|
m
|
1.2~1.27
|
|
Max. breakout force
|
KN
|
≥150
|
|
Max. traction force
|
KN
|
≥160
|
|
Articulation angle
|
0
|
38
|
|
Gradeability
|
0
|
28
|
|
Wheel base
|
m
|
2.84
|
|
Tread
|
m
|
2.25
|
|
Tyre size
|
m
|
|
|
Min. ground clearance
|
m
|
0.534
|
|
Min. turning radius
|
m
|
5.765
|
|
Working speed
|
|
|
|
Hydraulic cycle time – raise
|
s
|
|
|
Total hydraulic cycle time
|
s
|
≤10
|
