Quick Details Feature: Wheel Loader Condition: New Application: Construction Brand Name: CHENGGONG Model Number: CG932H Certification: ISO,CE Rated Loading Capacity: 3.0t Bucket Capacity: 1.7-2.5m3 Dimension: 7055*2519*3186mm Max. Lifting Load: 3.0t Engine: CA6DF1D Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit CG932H Overall length mm 7055 Overall width mm 2519 Overall height mm 3186 Weight Total weight kg 9900 Power Engine model CA6DF1D Engine rated power kW 92 Engine rated speed r/min 2000 Travel Max. travel speed km/h 33 Main performance Rated load t 3.0 Bucket capacity m3 1.7-2.5 Dumping clearance m 2.965 Dumping reach m 0.95 Max. breakout force KN 106 Max. traction force KN Steering angle 0 Gradeability 0 Wheel base m 2.76 Tread m Tyre size m Min. ground clearance m Min. turning radius m 5.306 Working speed Boom cycle time – raise s 5.5 Total hydraulic cycle time s 9.8
Feature: Wheel Loader
Condition: New
Application: Construction
Brand Name: CHENGGONG
Model Number: CG932H
Certification: ISO,CE
Rated Loading Capacity: 3.0t
Bucket Capacity: 1.7-2.5m3
Dimension: 7055*2519*3186mm
Max. Lifting Load: 3.0t
Engine: CA6DF1D
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit CG932H Overall length mm 7055 Overall width mm 2519 Overall height mm 3186 Weight Total weight kg 9900 Power Engine model CA6DF1D Engine rated power kW 92 Engine rated speed r/min 2000 Travel Max. travel speed km/h 33 Main performance Rated load t 3.0 Bucket capacity m3 1.7-2.5 Dumping clearance m 2.965 Dumping reach m 0.95 Max. breakout force KN 106 Max. traction force KN Steering angle 0 Gradeability 0 Wheel base m 2.76 Tread m Tyre size m Min. ground clearance m Min. turning radius m 5.306 Working speed Boom cycle time – raise s 5.5 Total hydraulic cycle time s 9.8
Dimension
Unit
CG932H
Overall length
mm
7055
Overall width
2519
Overall height
3186
Weight
Total weight
kg
9900
Power
Engine model
CA6DF1D
Engine rated power
kW
92
Engine rated speed
r/min
2000
Travel
Max. travel speed
km/h
33
Main performance
Rated load
t
3.0
Bucket capacity
m3
1.7-2.5
Dumping clearance
m
2.965
Dumping reach
0.95
Max. breakout force
KN
106
Max. traction force
Steering angle
0
Gradeability
Wheel base
2.76
Tread
Tyre size
Min. ground clearance
Min. turning radius
5.306
Working speed
Boom cycle time – raise
s
5.5
Total hydraulic cycle time
9.8
