Quick Details Feature: Wheel Loader Condition: New Application: Construction Brand Name: CHENGGONG Model Number: CG938H Certification: ISO,CE Rated Loading Capacity: 3.8t Bucket Capacity: 2.1-2.5m3 Dimension: 7330×2675×3485mm Max. Lifting Load: 3.8t Engine: QSB6.7 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit CG938H Overall length mm 7330 Overall width mm 2675 Overall height mm 3485 Weight Total weight kg 12500 Power Engine model QSB6.7 Engine rated power kW 119 Engine rated speed r/min 2200 Travel Max. travel speed km/h 37 Main performance Rated load t 3.8 Bucket capacity m3 2.1-2.5 Dumping clearance m 2.949 Dumping reach m 0.923 Max. breakout force KN 120 Max. traction force KN Steering angle 0 Gradeability 0 Wheel base m 2.9 Tread m Tyre size m Min. ground clearance m Min. turning radius m 5.2 Working speed Boom cycle time – raise s 4.8 Total hydraulic cycle time s 9.8
Feature: Wheel Loader
Condition: New
Application: Construction
Brand Name: CHENGGONG
Model Number: CG938H
Certification: ISO,CE
Rated Loading Capacity: 3.8t
Bucket Capacity: 2.1-2.5m3
Dimension: 7330×2675×3485mm
Max. Lifting Load: 3.8t
Engine: QSB6.7
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit CG938H Overall length mm 7330 Overall width mm 2675 Overall height mm 3485 Weight Total weight kg 12500 Power Engine model QSB6.7 Engine rated power kW 119 Engine rated speed r/min 2200 Travel Max. travel speed km/h 37 Main performance Rated load t 3.8 Bucket capacity m3 2.1-2.5 Dumping clearance m 2.949 Dumping reach m 0.923 Max. breakout force KN 120 Max. traction force KN Steering angle 0 Gradeability 0 Wheel base m 2.9 Tread m Tyre size m Min. ground clearance m Min. turning radius m 5.2 Working speed Boom cycle time – raise s 4.8 Total hydraulic cycle time s 9.8
Dimension
Unit
CG938H
Overall length
mm
7330
Overall width
2675
Overall height
3485
Weight
Total weight
kg
12500
Power
Engine model
QSB6.7
Engine rated power
kW
119
Engine rated speed
r/min
2200
Travel
Max. travel speed
km/h
37
Main performance
Rated load
t
3.8
Bucket capacity
m3
2.1-2.5
Dumping clearance
m
2.949
Dumping reach
0.923
Max. breakout force
KN
120
Max. traction force
Steering angle
0
Gradeability
Wheel base
2.9
Tread
Tyre size
Min. ground clearance
Min. turning radius
5.2
Working speed
Boom cycle time – raise
s
4.8
Total hydraulic cycle time
9.8
