Quick Details
|
Feature: Wheel Loader
|
Condition: New
|
Application: Construction
|
|
Brand Name: SINOMACH
|
Model Number: 620CH
|
Certification: ISO,CE
|
|
Rated Loading Capacity: 1.7t
|
Bucket Capacity: 1.0m3
|
Dimension: 5835*2240*3548mm
|
|
Max. Lifting Load: 1.7t
|
Engine: 4BTA3.9-C110
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Color: Yellow
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
7~15 days
|
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
|
Dimension
|
Unit
|
620CH
|
|
Overall length
|
mm
|
5835
|
|
Overall width
|
mm
|
2240
|
|
Overall height
|
mm
|
3548
|
|
Weight
|
|
|
|
Total weight
|
kg
|
8000
|
|
Power
|
|
|
|
Engine model
|
|
4BTA3.9-C110
|
|
Engine rated power
|
kW
|
82
|
|
Engine rated speed
|
r/min
|
2200
|
|
Travel
|
|
|
|
Travel speed 1st (forward/backward)
|
km/h
|
6/6
|
|
Travel?speed 2st (forward/backward)
|
km/h
|
10/10
|
|
Main performance
|
|
|
|
Rated load
|
t
|
1.7
|
|
Bucket capacity
|
m3
|
1.0
|
|
Dumping clearance
|
m
|
2.714
|
|
Dumping reach
|
m
|
0.084
|
|
Max. breakout force
|
KN
|
60
|
|
Max. traction force
|
KN
|
|
|
Steering angle
|
0
|
55
|
|
Gradeability
|
0
|
30
|
|
Wheel base
|
m
|
2.1555
|
|
Tread
|
m
|
1.7/1.88
|
|
Tyre size
|
m
|
|
|
Min. ground clearance
|
m
|
0.275
|
|
Min. turning radius
|
m
|
4.38
|
|
Working speed
|
|
|
|
Lifting time of loading bucket
|
s
|
≤5.1
|
|
Lowering time of loading bucket
|
s
|
≤4.0
|
