Quick Details Feature: Excavator Condition: New Application: Construction Brand Name: SANY Model Number: SY55C-9 Certification: ISO,CE Rated Loading Capacity: 5.78t Bucket Capacity: 0.1-0.28m3 Dimension: 5925*2005*2595mm Max. Lifting Load: 5.78t Engine: 4JG1-NABGB-04-C2 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SY55C-9 Overall length mm 5925 Overall width mm 2005 Overall height mm 2595 Track shoe length mm 2545 Track shoe width mm Weight Total weight kg 5780 Power Engine model 4JG1-NABGB-04-C2 Engine rated power kW 40.9 Engine rated speed r/min 2100 Travel Travel speed km/h 3.73/2.4 Main performance Rated load t 5.78 Bucket capacity m3 0.1-0.28 Gradeability 0 70 Ground pressure kpa 32.75 Bucket digging force KN 45 Arm digging force KN 33 Max. tractive force KN Max. dumping clearance m 3.93 Max. digging depth m 3.815 Max. digging radius m 6.09 Min. swing radius m 2.555 Steering speed r/min 9.6 Track gauge m 1.6 Caterpillar wheelbase m 2.045 Min. ground clearance m 0.33
Feature: Excavator
Condition: New
Application: Construction
Brand Name: SANY
Model Number: SY55C-9
Certification: ISO,CE
Rated Loading Capacity: 5.78t
Bucket Capacity: 0.1-0.28m3
Dimension: 5925*2005*2595mm
Max. Lifting Load: 5.78t
Engine: 4JG1-NABGB-04-C2
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit SY55C-9 Overall length mm 5925 Overall width mm 2005 Overall height mm 2595 Track shoe length mm 2545 Track shoe width mm Weight Total weight kg 5780 Power Engine model 4JG1-NABGB-04-C2 Engine rated power kW 40.9 Engine rated speed r/min 2100 Travel Travel speed km/h 3.73/2.4 Main performance Rated load t 5.78 Bucket capacity m3 0.1-0.28 Gradeability 0 70 Ground pressure kpa 32.75 Bucket digging force KN 45 Arm digging force KN 33 Max. tractive force KN Max. dumping clearance m 3.93 Max. digging depth m 3.815 Max. digging radius m 6.09 Min. swing radius m 2.555 Steering speed r/min 9.6 Track gauge m 1.6 Caterpillar wheelbase m 2.045 Min. ground clearance m 0.33
Dimension
Unit
SY55C-9
Overall length
mm
5925
Overall width
2005
Overall height
2595
Track shoe length
2545
Track shoe width
Weight
Total weight
kg
5780
Power
Engine model
4JG1-NABGB-04-C2
Engine rated power
kW
40.9
Engine rated speed
r/min
2100
Travel
Travel speed
km/h
3.73/2.4
Main performance
Rated load
t
5.78
Bucket capacity
m3
0.1-0.28
Gradeability
0
70
Ground pressure
kpa
32.75
Bucket digging force
KN
45
Arm digging force
33
Max. tractive force
Max. dumping clearance
m
3.93
Max. digging depth
3.815
Max. digging radius
6.09
Min. swing radius
2.555
Steering speed
9.6
Track gauge
1.6
Caterpillar wheelbase
2.045
Min. ground clearance
0.33
