22.57ton Excavator R225LC-9V

Quick Details

Feature: Excavator	Condition: New	Application: Construction
Brand Name: HYUNDAI	Model Number: R225LC-9V	Certification: ISO,CE
Rated Loading Capacity: 22.57t	Bucket Capacity: 1.05m3	Dimension:  9550*2990*3080mm
Max. Lifting Load: 22.57t	Engine: B5.9-C	Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year	Color: Yellow	After-sales Service Provided: Engineers available to service machinery overseas

---

Packaging & Delivery

Packaging Details:	Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:	7~15 days

---

Main Features

1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly

Technical Parameters

Dimension	Unit	R225LC-9V
Overall length (Transportation)	mm	9550
Overall width (Transportation/operation)	mm	2990
Overall height (Transportation)	mm	3080
Track shoe length	mm
Track shoe width	mm
Weight
Total weight	kg	22570
Power
Engine model		B5.9-C
Engine rated power	kW	112
Engine rated speed	r/min	1950
Travel
Travel speed	km/h	5.3/3.4
Main performance
Rated load	t	22.57
Bucket capacity	m3	1.05
Gradeability	0	70
Ground pressure	kpa	0.48
Bucket digging force	KN
Arm digging force	KN
Max. tractive force	KN
Max. dumping clearance	m	6.78
Max. digging depth	m	6.73
Max. digging radius	m	9.98
Min. swing radius	m	3.74
Steering speed	r/min
Track gauge	m
Caterpillar wheelbase	m
Min. ground clearance	m
