16ton Asphalt Distributor Truck DGL5160GLS
Quick Details
|
Feature: Concrete Pump
|
Condition: New
|
Application: Construction
|
|
Brand Name: DAGANG
|
Model Number: DGL5160GLS
|
Certification: ISO,CE
|
|
Operation Weight: 16t
|
Chassis model: SX1165UN461
|
Dimension: 8900*2500*3320mm
|
|
Voltage: 380V
|
Engine?rated?power: 30KW
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Color: Optional Colour
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
30 days
|
Main Features
1. Asphalt spraying operations can be conducted through the operating panel in the cab by one operator or the driver.
2. The spraying width is adjustable. Each spraying nozzle can be controlled automatically and independently, and the maximum spraying width can reach 6 meters.
3. Unique nozzles design can achieve triple-overlapping asphalt spray to guarantee uniformly spraying.
4. Asphalt spraying amount can be metered and controlled, which is not affected by truck speed.
5. Equipped with safe and reliable automatic-control Burner and hot oil heating system.
6. The control system introduces modular design, which is easy for troubleshooting and maintenance.
7. A standby control system is available and can be started immediately to ensure non-stop spraying once the main control system failed.
8. The asphalt rubber distributor is equipped with two agitators on the top of tank.
9. Equipped with a flexible hand-spraying system.
10. Excellent heat-preserving performance and the average temperature drop is less than 1 ℃/h.
11. Asphalt can be filled and discharged by the pump as well as filling asphalt through the manhole.
|
Technical Parameters
|
Dimension
|
Unit
|
DGL5160GLS
|
|
Overall length
|
mm
|
8900
|
|
Overall width
|
mm
|
2500
|
|
Overall height
|
mm
|
3320
|
|
Weight
|
|
|
|
Total weight
|
kg
|
16000
|
|
Chassis parameters
|
|
|
|
Chassis model
|
|
SX1165UN461
|
|
Engine model
|
|
|
|
Engine rated power
|
kW
|
30
|
|
Main performance
|
|
|
|
Asphalt tank capacity
|
L
|
8000
|
|
Max. spraying width
|
m
|
6
|
|
Asphalt application rate
|
kg/m2
|
0.3～3.0
|
|
Spraying precision
|
%
|
±2
|
|
Asphalt heating mode
|
|
Burner and hot oil
|
|
Average temperature drop
|
℃/h
|
≤1
|
|
Thermal capacity of burner
|
kcal/h
|
14×104
|
|
