Quick Details Feature: All Terrain Crane Condition: New Application: Construction Brand Name: XCMG Model Number: QAY500 Certification: ISO,CE Rated Loading Capacity: 500t Rated Lifting Moment: 15190kN.M Dimension: 20900×3000×4000mm Max. Lifting Load: 500t Max. Lifting Height: 84m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Span:10.125/9.6m After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit QAY500 Overall length mm 20900 Overall width mm 3000 Overall height mm 4000 Weight Total weight in travel kg 96000 Front axle load kg 12000 Rear axle load kg 12000 Power Engine model OM906LA Engine rated power kW/(r/min) 205/2100 Engine rated torque N.m/(r/min) 1110/1200~1600 Travel Max. travel speed km/h 80 Min. turning diameter m 30 Min. ground clearance mm 330 Approach angle ° 13 Departure angle ° 15 Max. grade ability % 35 Fuel consumption for 100km L 105 Main performance Max. rated total lifting capacity t 500 Min. rated working radius m 3 Turning radius at turntable tail m 6.76 Max. lifting torque kN.m 15190 Base boom m 16.1 Fully extended boom m 84 Fully extended boom+ jib m 140 Longitudinal outrigger span m 10.125 Lateral outrigger span m 9.6 Working speed Boom luffing time s 125 Boomfull extension time s 960/900 Max. swing speed r/min 0.8 Max. speed of main winch (single rope) (no load) m/min 170 Max. speed of aux. winch (single rope) (no load) m/min 170
Feature: All Terrain Crane
Condition: New
Application: Construction
Brand Name: XCMG
Model Number: QAY500
Certification: ISO,CE
Rated Loading Capacity: 500t
Rated Lifting Moment: 15190kN.M
Dimension: 20900×3000×4000mm
Max. Lifting Load: 500t
Max. Lifting Height: 84m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Span:10.125/9.6m
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit QAY500 Overall length mm 20900 Overall width mm 3000 Overall height mm 4000 Weight Total weight in travel kg 96000 Front axle load kg 12000 Rear axle load kg 12000 Power Engine model OM906LA Engine rated power kW/(r/min) 205/2100 Engine rated torque N.m/(r/min) 1110/1200~1600 Travel Max. travel speed km/h 80 Min. turning diameter m 30 Min. ground clearance mm 330 Approach angle ° 13 Departure angle ° 15 Max. grade ability % 35 Fuel consumption for 100km L 105 Main performance Max. rated total lifting capacity t 500 Min. rated working radius m 3 Turning radius at turntable tail m 6.76 Max. lifting torque kN.m 15190 Base boom m 16.1 Fully extended boom m 84 Fully extended boom+ jib m 140 Longitudinal outrigger span m 10.125 Lateral outrigger span m 9.6 Working speed Boom luffing time s 125 Boomfull extension time s 960/900 Max. swing speed r/min 0.8 Max. speed of main winch (single rope) (no load) m/min 170 Max. speed of aux. winch (single rope) (no load) m/min 170
Dimension
Unit
QAY500
Overall length
mm
20900
Overall width
3000
Overall height
4000
Weight
Total weight in travel
kg
96000
Front axle load
12000
Rear axle load
Power
Engine model
OM906LA
Engine rated power
kW/(r/min)
205/2100
Engine rated torque
N.m/(r/min)
1110/1200~1600
Travel
Max. travel speed
km/h
80
Min. turning diameter
m
30
Min. ground clearance
330
Approach angle
°
13
Departure angle
15
Max. grade ability
%
35
Fuel consumption for 100km
L
105
Main performance
Max. rated total lifting capacity
t
500
Min. rated working radius
3
Turning radius at turntable tail
6.76
Max. lifting torque
kN.m
15190
Base boom
16.1
Fully extended boom
84
Fully extended boom+ jib
140
Longitudinal outrigger span
10.125
Lateral outrigger span
9.6
Working speed
Boom luffing time
s
125
Boomfull extension time
960/900
Max. swing speed
r/min
0.8
Max. speed of main winch (single rope) (no load)
m/min
170
Max. speed of aux. winch (single rope) (no load)
