Quick Details Feature: Wheel Loader Condition: New Application: Construction Brand Name: XCMG Model Number: ZL50GN Certification: ISO,CE Rated Loading Capacity: 5.0t Bucket Capacity: 2.5~5.0m3 Dimension: 8165×3016×3485mm Max. Lifting Load: 5.0t Engine: WD10G220E23 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit ZL50GN Overall length mm 8165 Overall width mm 3016 Overall height mm> 3485 Weight Total weight kg 17500±300 Power Engine model WD10G220E23 Engine rated power kW 162 Engine rated speed r/min 2000 Travel Travel speed 1st (forward/backward) km/h 0~11.5/16.5 Travel?speed 2st (forward/backward) km/h 0~38 Main performance Rated load t 5.0 Bucket capacity m3 2.5~5.0 Dumping clearance m 3.1~3.72 Dumping reach m 1.1~1.22 Max. breakout force KN 170±5 Max. traction force KN 165±5 Aticulation angle 0 35 Gradeability 0 30 Wheel base m 3.3 Tread m 2.25 Tyre size m 23.5-25-16PR Working speed Hydraulic cycle time – raise s ≤6.5 Total hydraulic cycle time s ≤11
Feature: Wheel Loader
Condition: New
Application: Construction
Brand Name: XCMG
Model Number: ZL50GN
Certification: ISO,CE
Rated Loading Capacity: 5.0t
Bucket Capacity: 2.5~5.0m3
Dimension: 8165×3016×3485mm
Max. Lifting Load: 5.0t
Engine: WD10G220E23
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit ZL50GN Overall length mm 8165 Overall width mm 3016 Overall height mm> 3485 Weight Total weight kg 17500±300 Power Engine model WD10G220E23 Engine rated power kW 162 Engine rated speed r/min 2000 Travel Travel speed 1st (forward/backward) km/h 0~11.5/16.5 Travel?speed 2st (forward/backward) km/h 0~38 Main performance Rated load t 5.0 Bucket capacity m3 2.5~5.0 Dumping clearance m 3.1~3.72 Dumping reach m 1.1~1.22 Max. breakout force KN 170±5 Max. traction force KN 165±5 Aticulation angle 0 35 Gradeability 0 30 Wheel base m 3.3 Tread m 2.25 Tyre size m 23.5-25-16PR Working speed Hydraulic cycle time – raise s ≤6.5 Total hydraulic cycle time s ≤11
Dimension
Unit
ZL50GN
Overall length
mm
8165
Overall width
3016
Overall height
mm>
3485
Weight
Total weight
kg
17500±300
Power
Engine model
WD10G220E23
Engine rated power
kW
162
Engine rated speed
r/min
2000
Travel
Travel speed 1st (forward/backward)
km/h
0~11.5/16.5
Travel?speed 2st (forward/backward)
0~38
Main performance
Rated load
t
5.0
Bucket capacity
m3
2.5~5.0
Dumping clearance
m
3.1~3.72
Dumping reach
1.1~1.22
Max. breakout force
KN
170±5
Max. traction force
165±5
Aticulation angle
0
35
Gradeability
30
Wheel base
3.3
Tread
2.25
Tyre size
23.5-25-16PR
Working speed
Hydraulic cycle time – raise
s
≤6.5
Total hydraulic cycle time
≤11
