Quick Details Feature: Wheel Loader Condition: New Application: Construction Brand Name: SDLG Model Number: LG933L Certification: ISO,CE Rated Loading Capacity: 3.0t Bucket Capacity: 1.4~3.0m3 Dimension: 7185×2510×3087mm Max. Lifting Load: 3.0t Engine: YC6J125Z-T21 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit LG933L Overall length mm 7185 Overall width mm 2510 Overall height mm> 3087 Weight Total weight kg 10200~10250 Power Engine model YC6J125Z-T21 Engine rated power kW 92 Engine rated speed r/min 2300 Travel Travel speed 1st (forward/backward) km/h 0~8/0~9 Travel?speed 2st (forward/backward) km/h 0~14/0~27 Main performance Rated load t 3.0 Bucket capacity m3 1.4~3.0 Dumping clearance m 2.95~3.278 Dumping reach m 1.02~1.05 Max. breakout force KN ≥96 Max. traction force KN ≥96 Articulation angle 0 45 Gradeability 0 30 Wheel base m 2.7 Tread m 1.865 Tyre size m Min. ground clearance m 0.37 Min. turning radius m 5.349 Working speed Hydraulic cycle time – raise s Total hydraulic cycle time s ≤9
Feature: Wheel Loader
Condition: New
Application: Construction
Brand Name: SDLG
Model Number: LG933L
Certification: ISO,CE
Rated Loading Capacity: 3.0t
Bucket Capacity: 1.4~3.0m3
Dimension: 7185×2510×3087mm
Max. Lifting Load: 3.0t
Engine: YC6J125Z-T21
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit LG933L Overall length mm 7185 Overall width mm 2510 Overall height mm> 3087 Weight Total weight kg 10200~10250 Power Engine model YC6J125Z-T21 Engine rated power kW 92 Engine rated speed r/min 2300 Travel Travel speed 1st (forward/backward) km/h 0~8/0~9 Travel?speed 2st (forward/backward) km/h 0~14/0~27 Main performance Rated load t 3.0 Bucket capacity m3 1.4~3.0 Dumping clearance m 2.95~3.278 Dumping reach m 1.02~1.05 Max. breakout force KN ≥96 Max. traction force KN ≥96 Articulation angle 0 45 Gradeability 0 30 Wheel base m 2.7 Tread m 1.865 Tyre size m Min. ground clearance m 0.37 Min. turning radius m 5.349 Working speed Hydraulic cycle time – raise s Total hydraulic cycle time s ≤9
Dimension
Unit
LG933L
Overall length
mm
7185
Overall width
2510
Overall height
mm>
3087
Weight
Total weight
kg
10200~10250
Power
Engine model
YC6J125Z-T21
Engine rated power
kW
92
Engine rated speed
r/min
2300
Travel
Travel speed 1st (forward/backward)
km/h
0~8/0~9
Travel?speed 2st (forward/backward)
0~14/0~27
Main performance
Rated load
t
3.0
Bucket capacity
m3
1.4~3.0
Dumping clearance
m
2.95~3.278
Dumping reach
1.02~1.05
Max. breakout force
KN
≥96
Max. traction force
Articulation angle
0
45
Gradeability
30
Wheel base
2.7
Tread
1.865
Tyre size
Min. ground clearance
0.37
Min. turning radius
5.349
Working speed
Hydraulic cycle time – raise
s
Total hydraulic cycle time
≤9
