Quick Details
|
Feature: Truck Crane
|
Condition: New
|
Application: Construction
|
|
Brand Name: XCMG
|
Model Number: QY20G.5
|
Certification: ISO,CE
|
|
Rated Loading Capacity: 20t
|
Rated Lifting Moment: 860kN.M
|
Dimension: 12400*2500*3320 kW/rpm
|
|
Max. Lifting Load: 20t
|
Max. Lifting Height: 32.76m
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Span: 4.97/5.4m
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
10 days
|
Main Features
1. Max lifting weight:20ton
2. Engine shangcai 192KW
3. Fully extended boom+jib42.12m
4. Engine:SC8DK260Q3
5. Base boom:833KN.m
|
Technical Parameters
|
Dimension
|
Unit
|
QY20G.5
|
|
Overall length
|
mm
|
12400
|
|
Overall width
|
mm
|
2500
|
|
Overall height
|
mm
|
3320
|
|
Weight
|
|
|
|
Total weight in travel
|
kg
|
26020
|
|
Front axle load
|
kg
|
6900
|
|
Rear axle load
|
kg
|
19120
|
|
Power
|
|
|
|
Engine model
|
|
SC8DK260Q3, WD615.327
|
|
Engine rated power
|
kW/(r/min)
|
192/2200, 198/2200
|
|
Engine rated torque
|
N.m/(r/min)
|
1100/1400, 1150/1400
|
|
Travel
|
|
|
|
Max. travel speed
|
km/h
|
75
|
|
Min. turning diameter
|
m
|
20
|
|
Min. ground clearance
|
mm
|
275
|
|
Approach angle
|
°
|
16
|
|
Departure angle
|
°
|
13
|
|
Max. grade ability
|
%
|
24
|
|
Fuel consumption for 100km
|
L
|
≈35
|
|
Main performance
|
|
|
|
Max. rated total lifting capacity
|
t
|
20
|
|
Min. rated working radius
|
m
|
3
|
|
Turning radius at turntable tail
|
m
|
3.385
|
|
Max. lifting torque
|
kN.m
|
860
|
|
Base boom
|
m
|
10.06
|
|
Fully extended boom
|
m
|
32.76
|
|
Fully extended boom+ jib
|
m
|
42.12
|
|
Longitudinal outrigger span
|
m
|
4.97
|
|
Lateral outrigger span
|
m
|
5.4
|
|
Working speed
|
|
|
|
Boom luffing time
|
s
|
75
|
|
Boomfull extension time
|
s
|
95
|
|
Max. swing speed
|
r/min
|
3
|
|
Max. speed of main winch (single rope) (no load)
|
m/min
|
100
|
|
Max. speed of aux. winch (single rope) (no load)
|
m/min
|
100
|
