10.5ton Telescopic Handler XT670-140



Quick Details

Feature: Telescopic Handler

Condition: New

Application: Construction

Brand Name: XCMG

Model Number: XT670-140

Certification: ISO,CE

Rated Loading Capacity: 7100kg

Engine: 1104D-44T / Duzts TD226B-4IG2

Dimension: 5560*2300*2565mm

Max. Lifting Height: 14000mm

Rated power: 74.5KW

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Min. Lifting Height: 1050mm

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

10 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

XT670-140

Overall length

mm

6290

Overall width

mm

2450

Overall height

mm

2725

Weight





Total weight in travel

kg

10500

Power





Engine model


1104D-44T / Duzts TD226B-4IG2

Engine rated power

kW

74.5

Rated speed

r/min

2200

Travel





Max. speed

km/h

35

Main performance





Departure angle

0

36.4

Min. turning radius

mm

4238

Max. climbing capacity

0

26.5

Foot brake / brake oil pressure

Mpa

wet type / 4.4

Min. ground clearance

mm

450

Wheel base

mm

3250

Max. lift capacity

kg

3500

Lift capacity to full height

kg

1350

Lift capacity at full reach

kg

225

Lift height

mm

13500

Reach at max. lift height

mm

1955
