Quick Details
|
Feature: Forklift
|
Condition: New
|
Application: Construction
|
|
Brand Name: YTO
|
Model Number: CPCD30
|
Certification: ISO,CE
|
|
Power type: Diesel
|
Engine: ISUZU
|
Dimension: 2770*1225*2160mm
|
|
Rated capacity: 3t
|
Rated power: 34.5/2500KW
|
Place of Origin: Henan, China (Mainland)
|
|
Warranty: 1 year
|
Transmission type: Hydraulic
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
10 days
|
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
|
Dimension
|
Unit
|
CPCD30
|
|
Overall length
|
mm
|
2770
|
|
Overall width
|
mm
|
1225
|
|
Overall height
|
mm
|
2160
|
|
Weight
|
|
|
|
Total weight in travel
|
kg
|
4280
|
|
Power
|
|
|
|
Engine model
|
|
ISUZU C240
|
|
Engine rated power
|
kW/(r/min)
|
34.5/2500
|
|
Max. rotation
|
Nm/rpm
|
134/1800
|
|
Travel
|
|
|
|
Travel brake
|
|
Hydraulic-Foot pedal
|
|
Parking brake
|
|
Mechanical-Hand level
|
|
Lift speed (with/without load)
|
mm/s
|
400/440
|
|
Lower speed (with/without load)
|
mm/s
|
＜600 / ＞300
|
|
Travel speed (with/without load)
|
km/h
|
18/19
|
|
Main performance
|
|
|
|
Max. gradeability (with load)
|
%
|
20
|
|
Rated capacity
|
kg
|
3000
|
|
Load center
|
mm
|
500
|
|
Lift height
|
mm
|
3000
|
|
Mast tilt angle (forward/backward)
|
Deg
|
6/12
|
|
Wheel base
|
mm
|
1700
|
|
Tread (front/rear)
|
mm
|
1000/980
|
|
Min. turning radius
|
mm
|
2410
|
