16ton Asphalt Distributor Truck XLS80A
Quick Details
|
Feature: Concrete Pump
|
Condition: New
|
Application: Construction
|
|
Brand Name: XCMG
|
Model Number: XLS80A
|
Certification: ISO,CE
|
|
Operation Weight: 16t
|
Chassis model: ZZ1161M5011D1
|
Dimension: 9270*2490*3350mm
|
|
Voltage: 380V
|
Engine rated power: 198KW
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Color: Optional Colour
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
30 days
|
Main Features
1. Asphalt spraying operations can be conducted through the operating panel in the cab by one operator or the driver.
2. The spraying width is adjustable. Each spraying nozzle can be controlled automatically and independently, and the maximum spraying width can reach 6 meters.
3. Unique nozzles design can achieve triple-overlapping asphalt spray to guarantee uniformly spraying.
4. Asphalt spraying amount can be metered and controlled, which is not affected by truck speed.
5. Equipped with safe and reliable automatic-control Burner and hot oil heating system.
6. The control system introduces modular design, which is easy for troubleshooting and maintenance.
7. A standby control system is available and can be started immediately to ensure non-stop spraying once the main control system failed.
8. The asphalt rubber distributor is equipped with two agitators on the top of tank.
9. Equipped with a flexible hand-spraying system.
10. Excellent heat-preserving performance and the average temperature drop is less than 1 ℃/h.
11. Asphalt can be filled and discharged by the pump as well as filling asphalt through the manhole.
|
Technical Parameters
|
Dimension
|
Unit
|
XLS80A
|
|
Product model
|
|
XZJ5161GLQ
|
|
Overall length
|
mm
|
9270
|
|
Overall width
|
mm
|
2490
|
|
Overall height
|
mm
|
3350
|
|
Weight
|
|
|
|
Operating weight
|
kg
|
16000
|
|
Chassis parameters
|
|
|
|
Chassis model
|
|
ZZ1161M5011D1
|
|
Drive type
|
|
4*2
|
|
Engine model
|
|
|
|
Engine rated power
|
kW
|
198
|
|
Main performance
|
|
|
|
Spraying width
|
mm
|
200～6000
|
|
Asphalt pump capacity
|
ml/r
|
1620
|
|
Spraying capacity
|
kg/m2
|
0.2～3.0
|
|
Distributing accuracy
|
%
|
±1.5
|
|
Asphalt tank rated capacity
|
L
|
8000
|
|
Thanks still asphalt
temperature drop
|
℃/h
|
1
|
|
Burner tank
|
L
|
60
|
|
Hydraulic tank
|
L
|
80
|
|
Spraying the rated pressure
|
Mpa
|
0.7
|
|
Quantity of nozzles
|
|
48
|
|
Max. travel speed
|
km/h
|
90
|
|
