Quick Details
|
Feature: Dump truck
|
Condition: New
|
Application: Construction
|
|
Brand Name: SHACMAN
|
Model Number: F2000
|
Certification: ISO,CCC
|
|
Rated Loading Capacity: 25t
|
Carriage: 5600*2300*1400mm
|
Dimension: 8275*2490*3450mm
|
|
Capacity: 18m3
|
Curb weight: 11200kg
|
Place of Origin: Shaanxi, China (Mainland)
|
|
Warranty: 1 year
|
Engine: WD12.336 336hp, Euro II
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
30 days
|
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
|
Dimension
|
Unit
|
F2000
|
|
Overall length
|
mm
|
8275
|
|
Overall width
|
mm
|
2490
|
|
Overall height
|
mm
|
3450
|
|
Cargo Dimension
|
mm
|
5600*2300*1400 ( bottom 8 mm, side 6mm)
|
|
Weight
|
|
|
|
Total weight
|
kg
|
25000
|
|
Rated loading capacity
|
kg
|
13670
|
|
Kerb mass
|
kg
|
11200
|
|
Power
|
|
|
|
Engine model
|
|
Steyr Engine, WD12.336, 336hp, E-II
|
|
Rated output power
|
kW
|
247
|
|
Torque
|
N.m r. p. m
|
1350/1300-1600
|
|
Displacement
|
L
|
11.596
|
|
Main performance
|
|
|
|
Cab
|
|
D’long F2000 lengthen cab, with A/C
|
|
Approach angle
|
0
|
16
|
|
Departure angle
|
0
|
66
|
|
Front axle
|
|
MAN 7.5T front axle
|
|
Drive axle
|
|
STR 13T×2 axle
|
|
Fuel type
|
|
Diesel
|
|
Fuel tank capacity
|
L
|
380
|
|
Clutch
|
|
φ430 diaphragm spring
|
|
Drive type
|
|
6*4
|
|
Wheel base
|
mm
|
3800+1350
|
|
Gearbox
|
|
12JS160T
|
|
Front overhang
|
mm
|
1525
|
|
Rear overhang
|
mm
|
1600
|
|
Track width (front/rear)
|
mm
|
1939/1800
|
|
Steering
|
|
ZF technology left-hand drive
|
|
Lifting style
|
|
Middle lift
|
|
Tyre
|
|
11.00-20
|
|
Min. turning diameter
|
m
|
18
|
|
Max. grade ability
|
%
|
30
|
|
Max. speed
|
km/h
|
77
|
|
Speed ratio
|
|
5.73
|
