Travel
|
|
Category
|
Item
|
Unit
|
Parameter
|
|
Chassis
|
Model
|
|
FM440
|
|
Manufacturer
|
|
VOLVO
|
|
Max. speed
|
km/h
|
90
|
|
Max. gradeability
|
|
38%
|
|
Min. turning diameter
|
m
|
27.4
|
|
Brake distance
|
m
|
≤10
|
|
Wheelbase
|
mm
|
1995+5205+1370+1450
|
|
Tread (front/rear)
|
mm
|
2028/1872
|
|
Approach angle/departure angle
|
。
|
18/11
|
|
Min. clearance
|
mm
|
270
|
|
Tyre specification
|
|
12.00R20
|
|
Engine
|
Model
|
|
D13
|
|
Output power
|
kw/(r/min)
|
324/1400~1800
|
|
Max. torque
|
N.m/(r/min)
|
2200/1050~1400
|
|
Displacement
|
l
|
12.8
|
|
Emission Standard
|
|
Nation III GBⅢ
|
|
Others
|
Dimension (Length×Width×Height)
|
mm
|
14885×2500×3990
|
|
Total vehicle weight
|
kg
|
49750
|
|
Fuel tank capacity
|
l
|
410
|
|
Fuel consumption per 100km
|
l/100km
|
50
|
|
Pumping operation
|
|
Pumping system
|
Theoretical output(high pressure/low pressure)
|
m3/h
|
100/163
|
|
Concrete pumping pressure(high pressure/low pressure)
|
Mpa
|
13/8
|
|
Theoretical pumping times(high pressure/low pressure)
|
次/min
|
13/21
|
|
Max. diameter of pumping concrete aggregate
|
|
40
|
|
Feeding height
|
|
1530
|
|
Placing boom
|
Pumping slump range
|
|
12-23
|
|
Reach height
|
|
55.7
|
|
Reach depth
|
|
44
|
|
Slewing radius
|
|
51.7
|
|
Slewing angle
|
|
364
|
|
1st boom stretch angle
|
|
96
|
|
2nd boom stretch angle
|
|
180
|
|
3rd boom stretch angle
|
|
180
|
|
4th boom stretch angle
|
|
180
|
|
5th boom stretch angle
|
|
260
|
|
Outrigger span
|
Overall outrigger span
|
11250±50
|
|
Front outrigger transverse span
|
11400±50
|
|
Rear outrigger transverse span
|
11300±50
|
|
Others
|
Dosing type
|
|
S valve
|
|
Lubricating method
|
|
Automatic lubrication
|
|
Controlling method
|
|
Manual/remote control
|
|
Water tank capacity
|
|
700
|
|
Max. pressure of water pump
|
|
2
|
