Quick Details Feature: Bulldozer Condition: New Application: Construction Brand Name: SHANTUI Model Number: SD32F Certification: ISO,CE Rated Loading Capacity: 3.72t Bucket Capacity: 10/11.7m3 Dimension: 6880*4130*3640mm Max. Lifting Load: 3.72t Engine: NTA855-C360S10 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SD32F Overall length mm 6880 Overall width mm 4130 Overall height mm 3640 Ground contact length of track mm 3150 Track shoe width mm 560 Weight Total weight kg 37200 Power Engine model NTA855-C360S10 Engine rated power kW 235 Engine rated speed r/min 2000 Travel Travel speed 1st (forward/backward) km/h 0~3.6/0~4.4 Travel speed 2st (forward/backward) km/h 0~6.6/0~7.8 Main performance Operation weight t 37.2 Blade capacity m3 10/11.7 Gradeability 0 30 Ground pressure kpa 0.105 Shovel blade width m 4.13 Shovel blade height m 1.59 Max. hoisting height m 1.56 Max. digging depth m 0.56 Max. gradient m 0.1 Track gauge m 2.14 Caterpillar track pitch m 0.2286 Min. swing radius m Min. ground clearance m
Feature: Bulldozer
Condition: New
Application: Construction
Brand Name: SHANTUI
Model Number: SD32F
Certification: ISO,CE
Rated Loading Capacity: 3.72t
Bucket Capacity: 10/11.7m3
Dimension: 6880*4130*3640mm
Max. Lifting Load: 3.72t
Engine: NTA855-C360S10
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit SD32F Overall length mm 6880 Overall width mm 4130 Overall height mm 3640 Ground contact length of track mm 3150 Track shoe width mm 560 Weight Total weight kg 37200 Power Engine model NTA855-C360S10 Engine rated power kW 235 Engine rated speed r/min 2000 Travel Travel speed 1st (forward/backward) km/h 0~3.6/0~4.4 Travel speed 2st (forward/backward) km/h 0~6.6/0~7.8 Main performance Operation weight t 37.2 Blade capacity m3 10/11.7 Gradeability 0 30 Ground pressure kpa 0.105 Shovel blade width m 4.13 Shovel blade height m 1.59 Max. hoisting height m 1.56 Max. digging depth m 0.56 Max. gradient m 0.1 Track gauge m 2.14 Caterpillar track pitch m 0.2286 Min. swing radius m Min. ground clearance m
Dimension
Unit
SD32F
Overall length
mm
6880
Overall width
4130
Overall height
3640
Ground contact length of track
3150
Track shoe width
560
Weight
Total weight
kg
37200
Power
Engine model
NTA855-C360S10
Engine rated power
kW
235
Engine rated speed
r/min
2000
Travel
Travel speed 1st (forward/backward)
km/h
0~3.6/0~4.4
Travel speed 2st (forward/backward)
0~6.6/0~7.8
Main performance
Operation weight
t
37.2
Blade capacity
m3
10/11.7
Gradeability
0
30
Ground pressure
kpa
0.105
Shovel blade width
m
4.13
Shovel blade height
1.59
Max. hoisting height
1.56
Max. digging depth
0.56
Max. gradient
0.1
Track gauge
2.14
Caterpillar track pitch
0.2286
Min. swing radius
Min. ground clearance
