Quick Details Feature: Bulldozer Condition: New Application: Construction Brand Name: SHANTUI Model Number: SD16T Certification: ISO,CE Rated Loading Capacity: 1.7t Bucket Capacity: 4.3/4.5m3 Dimension: 5140*3388*3032mm Max. Lifting Load: 1.7t Engine: WD10G178E25 / SC11CB184G2B1 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SD16T Overall length mm 5140 Overall width mm 3388 Overall height mm 3032 Ground contact length of track mm 2430 Track shoe width mm 510 Weight Total weight kg 17000 Power Engine model WD10G178E25 / SC11CB184G2B1 Engine rated power kW 120 Engine rated speed r/min 1850 Travel Travel speed 1st (forward/backward) km/h 0-2.67/0-3.48 Travel speed 2st (forward/backward) km/h 0-3.76/0-4.90 Main performance Operation weight t 17 Blade capacity m3 4.3/4.5 Gradeability 0 30 Ground pressure kpa 0.067 Shovel blade width m 3.388 Shovel blade height m 1.149 Max. hoisting height m 1.096 Max. digging depth m 0.54 Max. gradient m 0.4 Track gauge m 1.88 Caterpillar track pitch m 0.2032 Min. swing radius m 4.7 Min. ground clearance m 0.4
Feature: Bulldozer
Condition: New
Application: Construction
Brand Name: SHANTUI
Model Number: SD16T
Certification: ISO,CE
Rated Loading Capacity: 1.7t
Bucket Capacity: 4.3/4.5m3
Dimension: 5140*3388*3032mm
Max. Lifting Load: 1.7t
Engine: WD10G178E25 / SC11CB184G2B1
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit SD16T Overall length mm 5140 Overall width mm 3388 Overall height mm 3032 Ground contact length of track mm 2430 Track shoe width mm 510 Weight Total weight kg 17000 Power Engine model WD10G178E25 / SC11CB184G2B1 Engine rated power kW 120 Engine rated speed r/min 1850 Travel Travel speed 1st (forward/backward) km/h 0-2.67/0-3.48 Travel speed 2st (forward/backward) km/h 0-3.76/0-4.90 Main performance Operation weight t 17 Blade capacity m3 4.3/4.5 Gradeability 0 30 Ground pressure kpa 0.067 Shovel blade width m 3.388 Shovel blade height m 1.149 Max. hoisting height m 1.096 Max. digging depth m 0.54 Max. gradient m 0.4 Track gauge m 1.88 Caterpillar track pitch m 0.2032 Min. swing radius m 4.7 Min. ground clearance m 0.4
Dimension
Unit
SD16T
Overall length
mm
5140
Overall width
3388
Overall height
3032
Ground contact length of track
2430
Track shoe width
510
Weight
Total weight
kg
17000
Power
Engine model
WD10G178E25 / SC11CB184G2B1
Engine rated power
kW
120
Engine rated speed
r/min
1850
Travel
Travel speed 1st (forward/backward)
km/h
0-2.67/0-3.48
Travel speed 2st (forward/backward)
0-3.76/0-4.90
Main performance
Operation weight
t
17
Blade capacity
m3
4.3/4.5
Gradeability
0
30
Ground pressure
kpa
0.067
Shovel blade width
m
3.388
Shovel blade height
1.149
Max. hoisting height
1.096
Max. digging depth
0.54
Max. gradient
0.4
Track gauge
1.88
Caterpillar track pitch
0.2032
Min. swing radius
4.7
Min. ground clearance
