Quick Details Feature: Bulldozer Condition: New Application: Construction Brand Name: HBXG Model Number: SD6GLGP Certification: ISO,CE Gradeability: 30/250 Bucket Capacity: 4m3 Dimension: 5212*3770*3192mm Ground pressure: 32.45kpa Engine: SC11CB184G2B1 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SD6GLGP Overall length mm 5212 Overall width mm 3770 Overall height mm 3192 Ground contact length of track mm Track shoe width mm 930 Weight Total weight kg 17300 Power Engine model SC11CB184G2B1 Engine rated power kW 119 Engine rated speed r/min 1900 Travel Travel speed 1st (forward/backward) km/h 0~4/0~4.8 Travel speed 2st (forward/backward) km/h 0~6.9/0~8.4 Main performance Operation weight t 17.3 Blade capacity m3 4 Gradeability 0 30/25 Ground pressure kpa 32.45 Shovel blade width m 3.77 Shovel blade height m Max. hoisting height m Max. digging depth m 0.592 Max. gradient m Track gauge m Caterpillar track pitch m 0.2082 Min. swing radius m Min. ground clearance m 0.445
Feature: Bulldozer
Condition: New
Application: Construction
Brand Name: HBXG
Model Number: SD6GLGP
Certification: ISO,CE
Gradeability: 30/250
Bucket Capacity: 4m3
Dimension: 5212*3770*3192mm
Ground pressure: 32.45kpa
Engine: SC11CB184G2B1
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit SD6GLGP Overall length mm 5212 Overall width mm 3770 Overall height mm 3192 Ground contact length of track mm Track shoe width mm 930 Weight Total weight kg 17300 Power Engine model SC11CB184G2B1 Engine rated power kW 119 Engine rated speed r/min 1900 Travel Travel speed 1st (forward/backward) km/h 0~4/0~4.8 Travel speed 2st (forward/backward) km/h 0~6.9/0~8.4 Main performance Operation weight t 17.3 Blade capacity m3 4 Gradeability 0 30/25 Ground pressure kpa 32.45 Shovel blade width m 3.77 Shovel blade height m Max. hoisting height m Max. digging depth m 0.592 Max. gradient m Track gauge m Caterpillar track pitch m 0.2082 Min. swing radius m Min. ground clearance m 0.445
Dimension
Unit
SD6GLGP
Overall length
mm
5212
Overall width
3770
Overall height
3192
Ground contact length of track
Track shoe width
930
Weight
Total weight
kg
17300
Power
Engine model
SC11CB184G2B1
Engine rated power
kW
119
Engine rated speed
r/min
1900
Travel
Travel speed 1st (forward/backward)
km/h
0~4/0~4.8
Travel speed 2st (forward/backward)
0~6.9/0~8.4
Main performance
Operation weight
t
17.3
Blade capacity
m3
4
Gradeability
0
30/25
Ground pressure
kpa
32.45
Shovel blade width
m
3.77
Shovel blade height
Max. hoisting height
Max. digging depth
0.592
Max. gradient
Track gauge
Caterpillar track pitch
0.2082
Min. swing radius
Min. ground clearance
0.445
