Quick Details Feature: Excavator Condition: New Application: Construction Brand Name: SANY Model Number: SY95C-9 Certification: ISO,CE Rated Loading Capacity: 8.85t Bucket Capacity: 0.2~0.45m3 Dimension: 6560*2260*2720mm Max. Lifting Load: 8.85t Engine: 4GJ1-TABA-01-C2 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SY95C-9 Overall length mm 6560 Overall width mm 2260 Overall height mm 2720 Track shoe length mm 2980 Track shoe width mm Weight Total weight kg 8850 Power Engine model 4GJ1-TABA-01-C2 Engine rated power kW 53.8 Engine rated speed r/min 2150 Travel Travel speed km/h 5.0/2.9 Main performance Rated load t 8.85 Bucket capacity m3 0.2~0.45 Gradeability 0 70 Ground pressure kpa 36 Bucket digging force KN 63.6 Arm digging force KN 46.8 Max. tractive force KN Max. dumping clearance m 5.21 Max. digging depth m 4.33 Max. digging radius m 6.66 Min. swing radius m 1.99 Steering speed r/min 11.2 Track gauge m 1.81 Caterpillar wheelbase m 2.34 Min. ground clearance m 0.36
Feature: Excavator
Condition: New
Application: Construction
Brand Name: SANY
Model Number: SY95C-9
Certification: ISO,CE
Rated Loading Capacity: 8.85t
Bucket Capacity: 0.2~0.45m3
Dimension: 6560*2260*2720mm
Max. Lifting Load: 8.85t
Engine: 4GJ1-TABA-01-C2
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit SY95C-9 Overall length mm 6560 Overall width mm 2260 Overall height mm 2720 Track shoe length mm 2980 Track shoe width mm Weight Total weight kg 8850 Power Engine model 4GJ1-TABA-01-C2 Engine rated power kW 53.8 Engine rated speed r/min 2150 Travel Travel speed km/h 5.0/2.9 Main performance Rated load t 8.85 Bucket capacity m3 0.2~0.45 Gradeability 0 70 Ground pressure kpa 36 Bucket digging force KN 63.6 Arm digging force KN 46.8 Max. tractive force KN Max. dumping clearance m 5.21 Max. digging depth m 4.33 Max. digging radius m 6.66 Min. swing radius m 1.99 Steering speed r/min 11.2 Track gauge m 1.81 Caterpillar wheelbase m 2.34 Min. ground clearance m 0.36
Dimension
Unit
SY95C-9
Overall length
mm
6560
Overall width
2260
Overall height
2720
Track shoe length
2980
Track shoe width
Weight
Total weight
kg
8850
Power
Engine model
4GJ1-TABA-01-C2
Engine rated power
kW
53.8
Engine rated speed
r/min
2150
Travel
Travel speed
km/h
5.0/2.9
Main performance
Rated load
t
8.85
Bucket capacity
m3
0.2~0.45
Gradeability
0
70
Ground pressure
kpa
36
Bucket digging force
KN
63.6
Arm digging force
46.8
Max. tractive force
Max. dumping clearance
m
5.21
Max. digging depth
4.33
Max. digging radius
6.66
Min. swing radius
1.99
Steering speed
11.2
Track gauge
1.81
Caterpillar wheelbase
2.34
Min. ground clearance
0.36
