Quick Details Feature: Excavator Condition: New Application: Construction Brand Name: SANY Model Number: SY465H-9 Certification: ISO,CE Rated Loading Capacity: 45.5t Bucket Capacity: 2.0~2.2m3 Dimension: 12200*3690*3880mm Max. Lifting Load: 45.5t Engine: Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SY465H-9 Overall length mm 12200 Overall width mm 3690 Overall height mm 3880 Track shoe length mm 5440 Track shoe width mm Weight Total weight kg 45500 Power Engine model Engine rated power kW 250 Engine rated speed r/min 2000 Travel Travel speed km/h 4.9/3.2 Main performance Rated load t 45.5 Bucket capacity m3 2.0~2.2 Gradeability 0 70 Ground pressure kpa 77 Bucket digging force KN 267 Arm digging force KN 241 Max. tractive force KN Max. dumping clearance m 7.445 Max. digging depth m 7.285 Max. digging radius m 11.56 Min. swing radius m 5.05 Steering speed r/min 10 Track gauge m 2.74 Caterpillar wheelbase m Min. ground clearance m 0.59
Feature: Excavator
Condition: New
Application: Construction
Brand Name: SANY
Model Number: SY465H-9
Certification: ISO,CE
Rated Loading Capacity: 45.5t
Bucket Capacity: 2.0~2.2m3
Dimension: 12200*3690*3880mm
Max. Lifting Load: 45.5t
Engine:
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit SY465H-9 Overall length mm 12200 Overall width mm 3690 Overall height mm 3880 Track shoe length mm 5440 Track shoe width mm Weight Total weight kg 45500 Power Engine model Engine rated power kW 250 Engine rated speed r/min 2000 Travel Travel speed km/h 4.9/3.2 Main performance Rated load t 45.5 Bucket capacity m3 2.0~2.2 Gradeability 0 70 Ground pressure kpa 77 Bucket digging force KN 267 Arm digging force KN 241 Max. tractive force KN Max. dumping clearance m 7.445 Max. digging depth m 7.285 Max. digging radius m 11.56 Min. swing radius m 5.05 Steering speed r/min 10 Track gauge m 2.74 Caterpillar wheelbase m Min. ground clearance m 0.59
Dimension
Unit
SY465H-9
Overall length
mm
12200
Overall width
3690
Overall height
3880
Track shoe length
5440
Track shoe width
Weight
Total weight
kg
45500
Power
Engine model
Engine rated power
kW
250
Engine rated speed
r/min
2000
Travel
Travel speed
km/h
4.9/3.2
Main performance
Rated load
t
45.5
Bucket capacity
m3
2.0~2.2
Gradeability
0
70
Ground pressure
kpa
77
Bucket digging force
KN
267
Arm digging force
241
Max. tractive force
Max. dumping clearance
m
7.445
Max. digging depth
7.285
Max. digging radius
11.56
Min. swing radius
5.05
Steering speed
10
Track gauge
2.74
Caterpillar wheelbase
Min. ground clearance
0.59
