Quick Details Feature: Wheel Loader Condition: New Application: Construction Brand Name: SDLG Model Number: LG952H Certification: ISO,CE Rated Loading Capacity: 5.0t Bucket Capacity: 2.4~4.5m3 Dimension: 7912×3024×3349mm Max. Lifting Load: 5.0t Engine: WD10G220E23 Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit LG952H Overall length mm 7912 Overall width mm 3024 Overall height mm> 3349 Weight Total weight kg 16400~16450 Power Engine model WD10G220E23 Engine rated power kW 162 Engine rated speed r/min 2000 Travel Travel speed 1st (forward/backward) km/h 0~13/0~17 Travel?speed 2st (forward/backward) km/h 0~38 Main performance Rated load t 5.0 Bucket capacity m3 2.4~4.5 Dumping clearance m 3.07~3.37 Dumping reach m 1.16~1.19 Max. breakout force KN ≥150 Max. traction force KN ≥160 Articulation angle 0 41 Gradeability 0 28 Wheel base m 2.84 Tread m 2.25 Tyre size m Min. ground clearance m 0.534 Min. turning radius m 5.765 Working speed Hydraulic cycle time – raise s Total hydraulic cycle time s ≤10
Feature: Wheel Loader
Condition: New
Application: Construction
Brand Name: SDLG
Model Number: LG952H
Certification: ISO,CE
Rated Loading Capacity: 5.0t
Bucket Capacity: 2.4~4.5m3
Dimension: 7912×3024×3349mm
Max. Lifting Load: 5.0t
Engine: WD10G220E23
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit LG952H Overall length mm 7912 Overall width mm 3024 Overall height mm> 3349 Weight Total weight kg 16400~16450 Power Engine model WD10G220E23 Engine rated power kW 162 Engine rated speed r/min 2000 Travel Travel speed 1st (forward/backward) km/h 0~13/0~17 Travel?speed 2st (forward/backward) km/h 0~38 Main performance Rated load t 5.0 Bucket capacity m3 2.4~4.5 Dumping clearance m 3.07~3.37 Dumping reach m 1.16~1.19 Max. breakout force KN ≥150 Max. traction force KN ≥160 Articulation angle 0 41 Gradeability 0 28 Wheel base m 2.84 Tread m 2.25 Tyre size m Min. ground clearance m 0.534 Min. turning radius m 5.765 Working speed Hydraulic cycle time – raise s Total hydraulic cycle time s ≤10
Dimension
Unit
LG952H
Overall length
mm
7912
Overall width
3024
Overall height
mm>
3349
Weight
Total weight
kg
16400~16450
Power
Engine model
WD10G220E23
Engine rated power
kW
162
Engine rated speed
r/min
2000
Travel
Travel speed 1st (forward/backward)
km/h
0~13/0~17
Travel?speed 2st (forward/backward)
0~38
Main performance
Rated load
t
5.0
Bucket capacity
m3
2.4~4.5
Dumping clearance
m
3.07~3.37
Dumping reach
1.16~1.19
Max. breakout force
KN
≥150
Max. traction force
≥160
Articulation angle
0
41
Gradeability
28
Wheel base
2.84
Tread
2.25
Tyre size
Min. ground clearance
0.534
Min. turning radius
5.765
Working speed
Hydraulic cycle time – raise
s
Total hydraulic cycle time
≤10
