Quick Details
|
Feature: Wheel Loader
|
Condition: New
|
Application: Construction
|
|
Brand Name: SHANTUI
|
Model Number: SL80W
|
Certification: ISO,CE
|
|
Rated Loading Capacity: 8t
|
Bucket Capacity: 4.5m3
|
Dimension: 9649×3340×3718mm
|
|
Max. Lifting Load: 8t
|
Engine: WD12G336E211
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Color: Yellow
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
7~15 days
|
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
|
Dimension |
Unit |
SL80W |
|
Overall length |
mm |
9649 |
|
Overall width |
mm |
3340 |
|
Overall height |
mm> |
3718 |
|
Weight |
|
|
|
Total weight |
kg |
29500 |
|
Power |
|
|
|
Engine model |
|
WD12G336E211 |
|
Engine rated power |
kW |
247 |
|
Engine rated speed |
r/min |
2200 |
|
Travel |
|
|
|
Travel speed 1st (forward/backward) |
km/h |
0~6.85/0~6.6 |
|
Travel?speed 2st (forward/backward) |
km/h |
0~10.5/0~18 |
|
Main performance |
|
|
|
Rated load |
t |
8 |
|
Bucket capacity |
m3 |
4.5 |
|
Dumping clearance |
m |
3.465 |
|
Dumping reach |
m |
1.426 |
|
Max. breakout force |
KN |
260 |
|
Max. traction force |
KN |
260 |
|
Articulation angle |
0 |
|
|
Gradeability |
0 |
|
|
Wheel base |
m |
3.74 |
|
Tread |
m |
2.59 |
|
Min. ground clearance |
m |
|
|
Min. turning radius |
m |
7.484 |
|
Working speed |
|
|
|
Hydraulic cycle time – raise |
s |
|
|
Total hydraulic cycle time |
s |
|
