Quick Details
|
Feature: Wheel Loader
|
Condition: New
|
Application: Construction
|
|
Brand Name: LIUGONG
|
Model Number: CLG842
|
Certification: ISO,CE
|
|
Rated Loading Capacity: 4.0t
|
Bucket Capacity: 2.3m3
|
Dimension: 7257*2466*3347mm
|
|
Max. Lifting Load: 4.0t
|
Engine: D6114ZG9B
|
Place of Origin: Jiangsu, China (Mainland)
|
|
Warranty: 1 year
|
Color: Yellow
|
After-sales Service Provided: Engineers available to service machinery overseas
|
Packaging & Delivery
|
Packaging Details:
|
Nude package Shipped by Ro-Ro or Bulk shipment
|
|
Delivery Detail:
|
7~15 days
|
Main Features
1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly
|
Technical Parameters
|
Dimension |
Unit |
CLG842 |
|
Overall length |
mm |
7257 |
|
Overall width |
mm |
2466 |
|
Overall height |
mm> |
3347 |
|
Weight |
|
|
|
Total weight |
kg |
13700 |
|
Power |
|
|
|
Engine model |
|
D6114ZG9B |
|
Engine rated power |
kW |
125 |
|
Engine rated speed |
r/min |
2200 |
|
Travel |
|
|
|
Travel speed 1st (forward/backward) |
km/h |
6.8/6.8 |
|
Travel?speed 2st (forward/backward) |
km/h |
11.8/11.8 |
|
Main performance |
|
|
|
Rated load |
t |
4.0 |
|
Bucket capacity |
m3 |
2.3 |
|
Dumping clearance |
m |
|
|
Dumping reach |
m |
|
|
Max. breakout force |
KN |
125±5 |
|
Max. traction force |
KN |
119 |
|
Articulation angle |
0 |
|
|
Gradeability |
0 |
|
|
Wheel base |
m |
3.0 |
|
Tread |
m |
2.47 |
|
Tyre size |
m |
20.5-25 |
|
Min. ground clearance |
m |
50 |
|
Min. turning radius |
m |
5.591±100 |
|
Working speed |
|
|
|
Boom cycle time – raise |
s |
5.7 |
|
Total hydraulic cycle time |
s |
9.9 |
