Quick Details Feature: Crawler Crane Condition: New Application: Construction Brand Name: XCMG Model Number: QUY100 Certification: ISO,CE Rated Loading Capacity: 100t Rated Lifting Moment: 5395kN.M Dimension: 9600*3300*3300mm Max. Lifting Load: 100t Max. Lifting Height: 72m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit QUY100 Overall length mm 9600 Overall width mm 3300 Overall height mm 3300 Weight Total mass (main hook block, 18m boom) t 114 Max. weight of base machine for transport t 40 Power Engine model Volvo TAD722VE Engine rated power kW/(r/min) 200 Engine rated torque N.m/(r/min) Travel Max. travel speed km/h 1.1 Max. grade ability % 30 Mean ground pressure MPa 0.0927 Main performance Max. rated total lifting capacity t 100 Max. lifting torque kN.m 5395 Base boom m 18 Fully extended boom m 72 Fully extended boom+ jib m 96 Boom elevating angle ° 0～80 Working speed Max. swing speed r/min 1.4 Max. single rope hoist speed (no-load, sixth floor) m/min 100 Max. single rope boom luffer speed (layer 1) m/min 45
Feature: Crawler Crane
Condition: New
Application: Construction
Brand Name: XCMG
Model Number: QUY100
Certification: ISO,CE
Rated Loading Capacity: 100t
Rated Lifting Moment: 5395kN.M
Dimension: 9600*3300*3300mm
Max. Lifting Load: 100t
Max. Lifting Height: 72m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit QUY100 Overall length mm 9600 Overall width mm 3300 Overall height mm 3300 Weight Total mass (main hook block, 18m boom) t 114 Max. weight of base machine for transport t 40 Power Engine model Volvo TAD722VE Engine rated power kW/(r/min) 200 Engine rated torque N.m/(r/min) Travel Max. travel speed km/h 1.1 Max. grade ability % 30 Mean ground pressure MPa 0.0927 Main performance Max. rated total lifting capacity t 100 Max. lifting torque kN.m 5395 Base boom m 18 Fully extended boom m 72 Fully extended boom+ jib m 96 Boom elevating angle ° 0～80 Working speed Max. swing speed r/min 1.4 Max. single rope hoist speed (no-load, sixth floor) m/min 100 Max. single rope boom luffer speed (layer 1) m/min 45
Dimension
Unit
QUY100
Overall length
mm
9600
Overall width
3300
Overall height
Weight
Total mass (main hook block, 18m boom)
t
114
Max. weight of base machine for transport
40
Power
Engine model
Volvo TAD722VE
Engine rated power
kW/(r/min)
200
Engine rated torque
N.m/(r/min)
Travel
Max. travel speed
km/h
1.1
Max. grade ability
%
30
Mean ground pressure
MPa
0.0927
Main performance
Max. rated total lifting capacity
100
Max. lifting torque
kN.m
5395
Base boom
m
18
Fully extended boom
72
Fully extended boom+ jib
96
Boom elevating angle
°
0～80
Working speed
Max. swing speed
r/min
1.4
Max. single rope hoist speed (no-load, sixth floor)
m/min
Max. single rope boom luffer speed (layer 1)
45
