Quick Details Feature: Crawler Crane Condition: New Application: Construction Brand Name: SMARTER Model Number: SMQ500D Certification: ISO,CE Rated Loading Capacity: 50t Rated Lifting Moment: kN.M Dimension: 13914*4760*3020mm Max. Lifting Load: 50t Max. Lifting Height: 40m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: White After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit SMQ500D Overall length mm 13914 Overall width mm 4760 Overall height mm 3020 Weight Total mass (with basic boom) t 57.8 Balance weight t 18 Power Engine model Engine rated power kW/(r/min) 153/2200 Engine rated torque N.m/(r/min) Travel Max. travel speed km/h 0~2.4 Max. grade ability % 40 Mean ground pressure MPa Main performance Max. rated total lifting capacity t 50 Max. lifting torque kN.m Base boom m 10.8 Fully extended boom m 40 Fully extended boom+ jib m 47.5 Boom elevating angle ° -2~78 Working speed Max. swing speed r/min 0~1.8 Max. single rope hoist speed m/min 130 Max. single rope boom luffer speed m/min
Feature: Crawler Crane
Condition: New
Application: Construction
Brand Name: SMARTER
Model Number: SMQ500D
Certification: ISO,CE
Rated Loading Capacity: 50t
Rated Lifting Moment: kN.M
Dimension: 13914*4760*3020mm
Max. Lifting Load: 50t
Max. Lifting Height: 40m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: White
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit SMQ500D Overall length mm 13914 Overall width mm 4760 Overall height mm 3020 Weight Total mass (with basic boom) t 57.8 Balance weight t 18 Power Engine model Engine rated power kW/(r/min) 153/2200 Engine rated torque N.m/(r/min) Travel Max. travel speed km/h 0~2.4 Max. grade ability % 40 Mean ground pressure MPa Main performance Max. rated total lifting capacity t 50 Max. lifting torque kN.m Base boom m 10.8 Fully extended boom m 40 Fully extended boom+ jib m 47.5 Boom elevating angle ° -2~78 Working speed Max. swing speed r/min 0~1.8 Max. single rope hoist speed m/min 130 Max. single rope boom luffer speed m/min
Dimension
Unit
SMQ500D
Overall length
mm
13914
Overall width
4760
Overall height
3020
Weight
Total mass (with basic boom)
t
57.8
Balance weight
18
Power
Engine model
Engine rated power
kW/(r/min)
153/2200
Engine rated torque
N.m/(r/min)
Travel
Max. travel speed
km/h
0~2.4
Max. grade ability
%
40
Mean ground pressure
MPa
Main performance
Max. rated total lifting capacity
50
Max. lifting torque
kN.m
Base boom
m
10.8
Fully extended boom
Fully extended boom+ jib
47.5
Boom elevating angle
°
-2~78
Working speed
Max. swing speed
r/min
0~1.8
Max. single rope hoist speed
m/min
130
Max. single rope boom luffer speed
